Bass zvučnik Eminence Delta Pro 18A

Each Eminence Professional model can be identified by its cast aluminum Eminence chassis that is lightweight and strong. Aluminum does not conduct the magnetic field out of the gap, thereby making the motor strength higher and the stray magnetic field lower. We coat each chassis and all metal components with an epoxy-acrylic finish using our in-house e-coat process. We can control the thickness of that coating to within 0.001”; critical when working with close tolerance transducer motor designs. We then add front and rear sealing gaskets on each model to accommodate front or rear loading.


SPECIFICATION
Nominal Basket Diameter 18", 457 mm
Nominal Impedance* 8 Ω
Power Rating**
Watts 500 W
Music Program 1000 W
Resonance 28 Hz
Usable Frequency Range 37 Hz - 0.2 kHz
Sensitivity*** 96 dB
Magnet Weight 67 oz.
Gap Height 0.38", 9.7 mm
Voice Coil Diameter 2.5", 64 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs) 28 Hz
DC Resistance (Re) 5.3 Ω
Coil Inductance (Le) 3.43m H
Mechanical Q (Qms) 10.38
Electromagnetic Q (Qes) 0.33
Total Q (Qts) 0.32
Compliance Equivalent Volume (Vas) 493.2 liters / 17.42 cu.ft.
Peak Diaphragm Displacement Volume (Vd) 796 cc
Mechanical Compliance of Suspension (Cms) 0.25 mm/N
BL Product (BL) 18.9 T-M
Diaphragm Mass Inc. Airload (MMs) 128 grams
Efficiency Bandwidth Product (EBP) 84
Maximum Linear Excursion (Xmax) 6.7 mm
Surface Area of Cone (Sd) 1188 cm2
Maximum Mechanical Limit (Xlim) 15. mm
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed N/a
Vented 85-297 liters / 3-10.5 cu.ft.
Driver Volume Displaced 0.212 cu.ft. / 6.01 liters
Overall Diameter 18", 457.2 mm
Baffle Hole Diameter 16.57", 420.9 mm
Front Sealing Gasket Yes
Rear Sealing Gasket Yes
Mounting Holes Diameter 0.28", 7.1mm
Mounting Holes B.C.D. 17.25", 438.2mm
Depth 8.13", 206.5 mm
Net Weight 17 lbs, 7.71 kg
Shipping Weight 20.5 lbs, 9.3 kgs
MATERIALS OF CONSTRUCTION
Coil Construction Copper voice coil
Coil Former Polyimide former
Magnet Composition Ferrite magnet
Core Details Vented and extended core

Basket Materials Die-cast aluminum basket
Cone Composition Paper cone
Cone Edge Composition Cloth cone edge
Dust Cap Composition Solid composition paper dust cap

Cijena za gotovinsko plaćanje : 1.649,00 HRK

Za sve ostale informacije slobodno nas kontaktirajte ili posjetite player.hr
