Agregat za struju pramac qsv 275 kva najam

Engine specifications
Engine manufacturer
Model
[50Hz] Exhaust emission level
Engine cooling system
Nr. of cylinder and disposition
Displacement cm3 Aspiration
Volvo
TAD734GE
Stage II
Water
6 in line
7150
Turbocharged intercooled
Speed governor
Prime gross power PRP
Maximum gross power LTP
Oil capacity
Lube oil consumption @ PRP (max) Coolant capacity
Fuel
Specific fuel consumption @ 75% PRP Specific fuel consumption @ PRP Starting system
Starting engine capability
Electric circuit
Electronic kW 227 kW 250 l 29 % 0.10 l 32 Diesel g/kWh 217 g/kWh 204 Electric kW 5 V 24
ENGINE EQUIPMENT
Standards
The engine performance corresponds to ISO 3046, BS 5514 and DIN 6271. Ratings are based on ISO 8528. Engine speed governing in accordance with ISO 3046/IV, class A1 and ISO 8528-5 class G3
Engine and block
• Optimized cast iron cylinder block with optimum distribution of forces
• Keystone top compression rings for long service life
• Replaceable valve guides and valve seats
Fuel system
• Common rail
• Engine mounted fuel pre-filter with water separator
• Fine fuel filter of cartridge insert type
• Gear driven fuel feed pump
Lubrication system
• Rotary displacement oil pump driven by the crankshaft
• Deep front oil sump ,Oil filler on top, Oil dipstick, short in front
• Integrated full flow oil cooler, side-mounted
Cooling system
• Belt driven, maintenance-free coolant pump with high degree of efficiency
• Efficient cooling with accurate coolant control through a water distribution duct in the cylinder block
• Reliable thermostat with minimum pressure drop
Intake and exhaust system
• Two-stage air filter, with cyclone
