SOtM sHP-100 USB DAC & visokokvalitetno pojačalo za slušalice

SOtM
sHP-100
USB DAC & visokokvalitetno pojačalo za slušalice
DAC / Headphone Amplifier

Značajke:
DAC & Headphone Amp
USB/Coax/Optical/analog input
Headphone/unbalance line output
24bit/192kHz PCM, DSD playback
External power operation

https://www.sotm-audio.com/sotmwp/english/portfolio-item/shp-100/
Specifikacije:
USB input
USB specification 2.0 or higher
USB audio class 2.0
Support 24bit/44, 48, 88.2, 96, 176.4, 192KHz PCM playback
Support 64x DSD, 128x DSD playback
Native ASIO support
Coaxial, Optical input
Max bit-depth : 24bit
Sampling rate : 32, 44.1, 48, 88.2, 96, 176.4, 192KHz
Coaxial impedance: 75Ω
Analog input
Maximum input voltage : 2Vrms
3.5mm stereo jack
Headphone output
Maximum output voltage @ low impedance output select: 0V ~ 2.1 Vrms (± 0.1Vrms)
High impedance output voltage gain : 4
Output impedance : 13Ω (include headphone amplifier chip)
THD+N : < 0.005% @ 1KHz, maximum output level
Line output
Fixed level output voltage : 2.7 Vrms (± 0.1Vrms)
Variable level output voltage : Refer headphone output voltage
Output impedance : 47Ω
THD+N : < 0.002% @ 1KHz, maximum output level
Indicate lamp
Input select lamp x 4 : USB, Coaxial, Optical, Analog
Mute indicate : Blink
Power input
Input voltage range : 7Vdc ~ 9Vdc
Input current : 2A max
Operation environment
Operating temperature : 10℃ ~ 35℃
Storage temperature : -10℃ ~ 50℃
Operating & storage humidity : 10% ~ 90%
Dimension / Weight
106mm x 53mm x 175mm / 1kg >

KOMPLETNA AMBALAŽA!
DRIVER!
Stanje: 5/5 besprijekorno
Starost: 2 mjeseca
CIJENA: 500€

Mogućnost zamjene za receiver

KONTAKT: 00385 98 227 602
E-MAIL: dado.audio@gmail.com
